Product Description
Steel 4xD Indexable Drill with a 1.250″ Diameter 5.585″ Drill Depth 1.250″ Shank Length to hold (2) WCMX 32.52 Coolant Thru
Product Specs
BD (Body Diameter) 1.73
DC (Cut Diameter) 1.25
DCONms (Connection Diameter) 1.25
L (Overall Length) 9.379
LF (Functional Length) 5.585
LPR (Protruding Length) 6.76
LS (Length of Shank) 2.619
LU (Usable Length) 5
