KITAGAWA 15" 3 JAW THRU HOLE LATHE POWER CHUCK B215
Product Description
Technical Specifications
Net Weight (lbs) 255
Max. Speed (rpm) 2800
Max. Gripping Force (lbs) 55977
Through Hole Diameter 3.937
Chuck Diameter 15
Model Number B215
Description Type B
Large Thru-Hole
Strong Clamping Force
High Speed
Compact and Lightweight
High Accuracy and High Endurance
Lubrication nipple in each base jaw.
Master Jaw Serration 1.5mm x 60
An Ajax Chuck and Jaw technician Welcomes the opportunity to help in selection of the proper Chuck and Jaws for your application and to quote Your Organization.
Ajax Sales & Service: 1 (800)543-5998
Net Weight (lbs) 255
Max. Speed (rpm) 2800
Max. Gripping Force (lbs) 55977
Through Hole Diameter 3.937
Chuck Diameter 15
Model Number B215
Description Type B
Large Thru-Hole
Strong Clamping Force
High Speed
Compact and Lightweight
High Accuracy and High Endurance
Lubrication nipple in each base jaw.
Master Jaw Serration 1.5mm x 60
An Ajax Chuck and Jaw technician Welcomes the opportunity to help in selection of the proper Chuck and Jaws for your application and to quote Your Organization.
Ajax Sales & Service: 1 (800)543-5998
