Rohm 5MT Revolving Tailstock Standard - Live Center

Rohm 5MT Revolving Tailstock Standard - Live Center
Item# 42843
$695.00
Availability: In Stock

Product Description

TECHNICAL SPECIFICATIONS

Accuracy .0002

Brand Name Rohm

Head Diameter 3.543

Head Length 5.079

Max. RPM 3000

Mount 5 MT

Point Diameter 1.575

Point Length 1.988

Point Style Standard

Radial Load 4400 lbs

Style Revolving Tailstock

Type Live CenterRevolving Tailstock Center

Type 604H body hardened and ground

Triple bearing method

High runout accuracy

Heavy duty

High speeds

Long life
