Product Description
VDI 3/4" B5 RH 30mm SH CNC Lathe Toolholder 25.3020.1
USA MADE
Specifications
Shank Diameter (mm) 30.00
Maximum Cutting Tool Size (Inch) 3/4
Projection (mm) 60.00
VDI Form Type B5 Through Coolant (Yes/No) Yes
Head Width (mm) 100.00
Features
For Mazak, Emco-Maier, Hitachi, Seiki, Okuma, Hass, Daewoo Hardinge.
Toolholders are precision ground, and Hardened.
Black-oxide finish for long lasting protection.
Material 8620 To DIN 69 880 specifications.
Ajax has a complete line of CNC VDI Toolholders, Tool Blocks and Live Tooling, Made to DIN 69880 standards and ISO 9001/2000 specifications.
Available VDI Shank Sizes: 16mm, 20mm, 25mm, 30mm, 40mm, 50mm, 60mm & 80mm.
Holds Standard Inch Size Tooling; Metric Available Upon Request.
VDI Provides a fast and accurate way of affixing tools to the Turret; Tool Changes are performed in seconds.
Toolholders can be Preset. By Cam Operated Clamping System.
Toolholders can be manufactured to meet your specifications.
PRICE IS LIST WE WELCOME THE OPPORTUNITY TO QUOTE
Additional Sizes
VDI Shank Size Part Number
20MM 25. 2016
25MM 25. 2516
30MM 25. 3020
40MM 25. 4025
50MM 25. 5032
60MM 25. 6032
